Professional SMT PCB Assembly and Through-Hole Technology (THT) Soldering
|
PCB Production Capacity
|
|
|
Layer Capabilities:
|
1 to 58 layers
|
|
Materials:
|
CME1, CME3, FR-4, High TG FR4, Halogen free FR4, Polyimide, aluminum, Ceramic(96% Alumina) Teflon, PTFE（F4B，F4BK）,Rogers（4003, 4350,5880）Taconic（TLX-8，TLX-9）, Arlon（35N、85N） etc.
|
|
Board Sizes:
|
Up to 800 × 508 mm (32″ x 20″)
|
|
Material Mixed Laminate:
|
4 layers -10 layers(FR4+Ro4350, FR4+Aluminum, FR4+ FPC)
|
|
Precision Tolerances:
|
Min track/gap of 0.075 mm, and dielectric thickness down to 0.1 mm
|
|
Minimum trace width and spacing:
|
0.075mm/0.075mm(3mil/3mil)
|
|
Minimum finished hole diameter:
|
0.15mm(6mil).0.1mm(4mil)for HDI
|
|
Surface finishes offered:
|
HASL(with lead),HASL(Lead free),Au and Nikle Gold plating, OSP, ENIG, ENEPIG, Immersion silver,Immersion Tin
|
|
PCBA Production Capacity
|
|
|
SMT Lines:
|
6 lines, capable of 7 million placements daily
|
|
Versatility:
|
Handles everything from prototyping to large-scale production with no MOQ
|
|
Solder Types:
|
Water Soluble, Leaded, and Lead-Free options available
|
|
Testing & Quality Control:
|
Includes X-Ray, AOI, ICT, Flying Probe, Burn-in, and Function Testing
|
|
Component Range:
|
0201 to BGA, CSP, and QFP
|
|
Speed & Efficiency:
|
0.15 sec/chip, 0.7 sec/QFPa
|
|
Through-Hole Assembly:
|
25,000 units per month
|
|
THT Equipment:
|
4 automatic soldering/testing lines
|
|
THT Full-Time Production Staff:
|
120+
|
|
Certifications held:
|
ISO 9001, ISO 13485, IATF 16949, RoHS.
|
|
Technical Details
|
||||
|
Min Components size
|
0201-54 sq.mm (0.084 sq.inch),Long Connector,CSP,BGA,QFP
|
|||
|
Speed
|
0.15sec/chip, 0.7sec/QFP
|
|||
|
Max.PCB Width:450mm
|
||||
|
Min.PCB Width:unlimited
|
||||
|
Wave-Solder
|
Components Height:Top 120mm/Bot 15mm
|
|||
|
Metal Types:Part,Whole,Inlay,Side-step
|
||||
|
Metal Material:Copper,Aluminum
|
||||
|
Sweat-Solder
|
Surface Finish:Plating Au,Plating Silver,Plating Sn
|
|||
|
Air Bladder Rate:less than 20%
|
||||
|
Press Range:0-50KN
|
||||
|
Press-fit
|
Max.PCB Size:800*600mm
|
|||
|
SMT and Thru-hole
|
||||
|
Solder Type
|
Water Soluble Solder Paste,Leaded and Lead-Free
|
|||
|
File Formats
|
BOM ,Gerber Files,Pick-N-Place Files(XYRS)
|
|||
|
Type of Service
|
Turn-Key,Partial Turn-Kye or Consignment
|
|||
|
Component Packaging
|
Cut Tape,Tube Reels Loose,Parts
|
|||
|
Testing
|
X-RAY Inspection,AOI Testing ICT,Flying Probe,Burn-in,Function Test
|
|||
